Hunter PGP Ultra Sprinklers

SKU:
SPR0105
UPC:
Hunter PGP Sprinklers PGS
Availability:
In Stock
Shipping:
Calculated at Checkout
£12.00
Inc. VAT
£10.00
Ex. VAT

Description

Hunter PGP Ultra SprinklersHunter PGP Sprinkler Heads

Action Packed and Feature Stacked

The new PGP Ultra is a blockbuster of epic proportions. Ready to thrill you, this action packed feature from the award-winning Hunter Industries stars the same great lineup of the original PGP: Through- the-top adjustment, large nozzle selection, and the industry’s most reliable and proven drive- train assembly. But the newcomers are what makes it Ultra: Full-circle adjustment from 50 to 360 degrees; non-strippable drive mechanism with auto-arc return; headed and slotted nozzle retainer screw, using either a Hunter wrench or a standard slotted screwdriver; and improved dirty-water tolerance on the internal gear drive.

Each PGP Ultra comes with an easy-to-install, square top rack of 8 standard nozzles and 4 low angle nozzles. And optional racks of short range nozzles, for the smallest of areas, are available, too.

 PGP Nozzle Set

CODE MODEL DESCRIPTION
SPR0105 PGS Ultra PGP Shrub Sprinkler: Full Circle 360° & Part Circle 50° - 360° & check valve
SPR0102 PGP Ultra 4" Pop-up sprinkler: Full Circle 360° & Part Circle 50° - 360° & check valve

DIMENSIONS

  • Overall height:
    PGP-00 – 7-3/8” (19 cm)
    PGP-04 – 7-3/8” (19 cm)
    PGP-12-CV – 17” (43 cm)
  • 3/4” female inlet BSP
  • Exposed diameter: 1-3/4” (4 cm)

Operating Specifications

  • Discharge rate: 0.9 to 14.8 GPM (0.20 to 3.36 m3/hr; 3.4 to 56.0 l/min)
  • Radius: 17' to 47' (5.2 to 14.3 m)
  • Recommended pressure range: 30 to 70 PSI (2.1 to 4.8 bars; 206 to 482 kPa)
  • Operating pressure range: 20 to 100 PSI (1.4 to 6.9 bars; 137 to 689 kPa)
  • Precipitation rates: approximately 0.4" (10 mm) per hour at 50 PSI (3.4 bars; 344 kPa) for spacing from 18' to 45' (5.5 to 13.7 m)
  • Nozzle trajectory: standard – 25˚; low angle – 13˚



Hunter Sprinkler Comparison Chart

Model Discharge Rate Pressure Range Radius
GPM m³/hr ltr/min PSI Bars Feet metres
PGJ 0.75 - 3.0 0.17 - 0.68 2.8 - 11.4 30 - 50 2.1 - 3.4 15' - 37' 4.6m - 11.3m
PGP 0.5 - 14.4 0.11 - 3.27 1.9 - 54.5 30 - 70 2.1 - 4.8 22' - 52' 6.7m - 15.8m
I-20 Ultra 0.5 - 14.4 0.11 - 3.27 1.9 - 54.5 30 - 70 2.1 - 4.8 17' - 47' 5.2m - 14.3m
I-25 Ultra 3.8 - 31.5 0.86 - 7.16 14.4 - 119.2 40 - 100 2.8 - 6.9 40' - 71' 12.2m - 21.6m
I-35 Sierra 7.7 - 31.0 1.65 - 7.24 27.5 - 120.7 40 - 100 2.8 - 6.9 47' - 71' 14.0m - 21.6m
I-40 Ultra 7.0 - 27.5 1.59 - 6.25 26.5 - 104.1 40 - 90 2.8 - 6.2 45' - 70' 13.7m - 21.3m
I-60 6.5 - 20.4 1.48 - 4.63 24.6 - 77.2 40 - 60 2.8 - 4.1 50' - 66' 15.2m - 20.1m
I-90 29.8 - 69.4 6.77 - 15.76 113 - 263 60 - 100 4.1 - 6.9 71' - 96' 21.0m - 29.3m
G870 13.0 - 32.0 2.95 - 7.27 49.2 - 121.1 50 - 100 3.4 - 6.9 53' - 78' 16.2m - 23.8m
G875 7.7 - 31.5 1.75 - 7.16 29.1 - 119.2 40 - 100 2.8 - 6.9 47' - 73' 14.3m - 22.3m
G990 26.4 - 62.7 6.00 - 14.24 100.0 - 237.3 60 - 100 4.1 - 6.9 69' - 100' 21.0m - 30.5m
G995 31.4 - 62.7 7.14 - 14.24 119.0 - 237.3 60 - 100 4.1 - 6.9 71' - 89' 21.0m - 27.1m

PGPmetric by Wayne Seaman on Scribd
